The blog based on Node.js server.

In front-end, we have several types to send a request to server, most of the time, we use 3 commonly below:

  1. application/json
  2. application/x-www-form-urlencoded
  3. multipart/form-data

application/json

GET

client

1
2
3
4
5
6
7
8
9
$.ajax({
  url: '/upload',
  method: 'GET',
  contentType: 'application/json',
  data: JSON.stringify({   // must turn to string, whether jQuery will turn to "x-www-form-urlcoded" format
    username: 'username',
    password: 'password'
  })
})

Check the request header in network panel in Chrome dev-tool, you will see the request URL turn to http://domain/upload?{"test":"wuyuchang","passowrd":"chang"}, it’s because GET request always append data to the request URL.

1
2
3
4
Request URL:http://domain/upload?{"test":"username","passowrd":"password"}
Request Method:GET
Content-Type:application/json
...

server

In server side, you can read the header that client send throw req.headers, and URL throw req.url, then you just compile analysis the parameter after question mark.

1
2
3
4
5
6
http.createServer((req, res) => {
  const qs = require('querystring')
  let param = qs.unescape(req.url.split('?')[1])
  let json = JSON.parse(param)
  // ...
}).listen(8080)

POST

Client

For client, you just change the request method from ‘GET’ to ‘POST’.

Server

In server side, you can’t get content that client send directly, it’s send throw buffer, so you have to receive it by listen it throw req.on(‘data’)

1
2
3
4
5
6
7
8
9
10
http.createServer((req, res) => {
  let chunk = ''
  req.on('data', data => {
    chunk += data
  })
  req.on('end', err => {
    let json = JSON.parse(chunk.toString())
    // ...
  })
}).listen(8080)

It’s convenient to get JSON data throw this way.

application/x-www-form-urlencoded

GET

Client

Same with above, just change the contenType to ‘application/x-www-form-urlencoded’, the jQuery wouldn’t add contentType automatic if you set method as ‘GET’.

server

1
2
3
4
http.createServer((req, res) => {
  let json = require('url').parse(req.url, true).query
  // ...
}).listen(8080)

POST

jQuery set contentType as ‘application/x-www-form-urlencoded’ if you send request throw ‘POST’ method.

server

1
2
3
4
5
6
7
8
9
10
11
http.createServer((req, res) => {
  let chunk = ''
  req.on('data', data => {
    chunk += data
  })
  req.on('end', err => {
    let qs = require('querystring')
    let json = qs.parse(chunk.toString())
    // ...
  })
}).listen(8080)

multipart/form-data

multipart/form-data always used to send a file, of course, you also can send form without file.

GET

It’s same with below, the different is that if you send a file to server, the server can’t accept it.

POST

Client

1
2
3
4
5
6
<form action="/upload" method="POST" enctype="multipart/form-data">
  <input type="text" name="test" value="wuyuchang">
  <input type="password" name="pwd" value="chang">
  <input type="file" multiple="multiple" name="upload"><br>
  <input type="submit" value="Upload">
</form>

the request header is different

1
2
3
4
5
6
7
8
9
10
11
12
13
Content-Type:multipart/form-data; boundary=----WebKitFormBoundaryuyeyXEbnVwhZJcl6
Request Payload:
  ------WebKitFormBoundaryuyeyXEbnVwhZJcl6
  Content-Disposition: form-data; name="test"

  wuyuchang
  ------WebKitFormBoundaryuyeyXEbnVwhZJcl6
  Content-Disposition: form-data; name="pwd"

  chang
  ------WebKitFormBoundaryuyeyXEbnVwhZJcl6
  Content-Disposition: form-data; name="upload"; filename="boom.png"
  Content-Type: image/png

the value of boundary is random.

Server

In server side you can compile it, but it’s complex, you can import a package name of ‘formidable’.
